Sequence

I receive many questions about how to influence the Rhapsody generated code. Now you can post-process the code using the simplifier or even change the rules with our rules-composer but sometimes you should make life not more complicated than it already is.
There are more ways to ensure Rhapsody generates exactly what you want.
Ask most modeling guru’s (and the traveling modeler agrees…) and they will tell you: You have to model in a way that sequence doesn’t matter. As already said: I agree. But…..
There are circumstances where you just cannot model as you want to. The smaller the controller, the more rigid the real-time requirements, the more trouble to fit everything in and to certify it works.

Classes

Open a new model and if you create 4 classes (in this sequence!) “A”, “B”, “D”, “C”, you will see in your browser that under the default package you have the 4 classes, sorted alfabetically, A, B, C, D. This is just the “visual” sort, you can switch that of with either a property or with “View”, “Browser Display options”, “Enable Ordering”. This will switch on the small yellow arrows on top of the browser that let you order items as you want. (Only Visual!!)

Now the sequence of Code generation is not relevant for classes since they have their own file. The sequence of attributes or operation within a class can be important!Now that can also be achieved easily. Rhapsody offers the sorting from within the browser. Depending on if you have switched on the “Enable Ordering” all elements

are either shown alfabetically or in the sequence that you have entered them in the model.
The code generation for attributes and operations is not depending on that setting!! Code is generated in alfabeticall sequence, or the sequence that you give in the “Edit Order of Attributes (Operations)”.
This opens a dialog where you can precisely select the generated source code sequence.

Now if you have created objects statically using “Make an Object” or by just creating them you can do the same. Right click on “Objects” and you can select “Edit order of Objects” you can select the order that the objects are instantiated. (Do a regenerate, Active Code View is not automatically updated) The same applies for singleton Objects.

This also works with dependencies (with Usage, that will select the sequence of include)

Happy modeling with Rhapsody
